THERMOSTAT REPLACMENT WITH PICTURES

Post by Bad Company on Mon Dec 24, 2012 7:39 pm

If you haven't done a t-stat replacement the first thing you will notice is there is no more flat round 2 hole gasket. There are 2 O rings, one on the inner metal disc that opens and closes to regulate the water tempature and a larger one around the outer t-stat itself. The inner one is usually the culprit, pulling away from the metal disc leaving a gap that you can barely get a pencil point into. That's all it takes to throw the P0128 code. Some brands of replacement t-stats do not have the inner ring.


When you get code P0128 (Engine Coolant Temperature (ECT) Below Thermostat Regulating Temperature). Replacing the thermostat is the usual repair for this code.



2007 Chevrolet HHR | HHR (VIN A) Service Manual | Document ID: 1833247
--------------------------------------------------------------------------------

Engine Coolant Thermostat Replacement:
Removal Procedure




Drain the cooling system.
Reposition the radiator outlet hose clamp at the thermostat housing.
Remove the radiator outlet hose from the thermostat housing.



Remove the thermostat housing cover bolts and cover.
Remove the thermostat.
Remove and discard the thermostat housing O-ring seal.
Installation Procedure




Install a NEW thermostat housing cover O-ring seal.
Install the thermostat.

Install the thermostat housing cover bolts.
Tighten
Tighten the bolts to 10 N·m (89 lb in).

Install the radiator outlet hose to the thermostat housing.
Position the radiator outlet hose clamp at the thermostat housing.
Fill the cooling system.


Dan



"We hang the petty thieves and appoint the great ones to public office "  - Aesop

Bad Company
Moderator
Moderator

Posts: 1633
Join date: 2012-11-02
Additional HHR Info: Gray Wolf 2006 Light Tarnished Silver Metallic LT 211,000 miles and counting. Little Red Mickey Victory Red 2LT 96,000 miles 2014 June HOTM


Back to top Go down

Re: THERMOSTAT REPLACMENT WITH PICTURES

Post by HHR Nole on Tue Dec 25, 2012 4:30 pm

Had to replace mine a couple of years ago,fortunely only took 15 min. because I don't have the stock airbox setup.Unfortunely it was the morning of my Dad's funeral and I had to have the car going Sad

HHR Nole
Enthusiast
Enthusiast

Posts: 2347
Join date: 2012-10-16
Age: 57
Additional HHR Info: "Nole" is a 2007 LT1 2.2L with just a "few" mods.Adopted 12/28/06. 2009 HoTY, 4 Time HoTM/HoTQ.


Back to top Go down

Re: THERMOSTAT REPLACMENT WITH PICTURES

Post by CJ on Tue Dec 25, 2012 7:24 pm

great one
